KKmoon 4pcs AHD 720P Weatherproof CCTV Cameras Kit IR CUT Color CMOS Home Security System 3.6mm


  • s385-uk
  • s385-eu


  • eu

Choose your country:

  • United Kingdom
Buy at Amazon
  • Overview
  • FAQ
  • -->

This camera needs to access AHD DVR.

This CCTV Camera Kit includes 4pcs color CMOS night vision 720P security cameras, 4pcs 60feet Video power cables for cameras, which form a full rage of 720P high-definition monitor experience to meet your need.
This bullet camera that has a great combination with 720P resolution and a 3.6mm lens is the most popular type of camera for outdoor and indoor use. With 24 built-in IR LEDs, this camera can capture video in night vision mode up to 65ft away. The aluminum frame is adopted to this bullet camera with nice shape. Its unique and adjustable bracket keep it can easily be mounted for the perfect viewing angle. The camera provide BNC connection for video and DC connection for power. Easy installation, just plug and play. Finally, this richly functional CCTV Camera Kit are affordable and practical.

* 1/4" CMOS, MTV3.6mm Lens.
* Horizontal Resolution 720P.
* 24 pcs IRφ5 LED, up to 65feet.
* IP66 rating, weatherProof.
* IR-CUT Automatic switching function.
* Plug and play.


Model No. TP-C217
Image Sensor 1/4"Color CMOS
Signal System PAL(Not suitable in America, Canada, Japan)
Horizontal Resolution 720P
Infrared Lamp 24pcsφ5 LED
Min. Illumination Day(0.1Lux), night(0.02Lux Open the lamp)
Lens 3.6mm
IR Distance 65feet
Day/Night YES
Gamma Correction 0.45
S/N Ratio ≥52db
Electronic Shutter 1/50-1/100,000S Auto/fixed
AGC Auto
BLC Auto
White Balance Auto/Manual
Video Output 1.0vp-p 75Ω BNC Connector
Synchronizing System Internal synchronization
Working Temperature -20°C to + 50°C
Waterproof Grade IP66
Color Adjustment 90mA-100mA / DC12V(without IR LED)
Power Consumption <12W
Color Black
Material Aluminium Alloy
Camera Size(Each) Approx.8.6 * 5.7 * 5.1cm / 3.39 * 2.24 * 2.01in( L * W * H )
Camera Weight(Each) Approx.156g / 5.51oz
Package Size Approx.38 * 10 * 26.7cm / 14.96 * 3.94 * 10.51in( L * W * H )
Total Weight Approx.2843g / 6.268Lb
Quantity 4pcs
Warranty 1 Year

Package list:
4 * 720P Waterproof IR-CUT Security Cameras
4 * 60ft (Video + Power) Cables for Cameras
4 * Mounting Brackets for Cameras
1 * Power Supply for Cameras (UK Plug)
4 * Accessories for Cameras
1 * 1 to 4 Power Splitter Line for Cameras
4 * Warning Signs
1 * User's Manual
